Amphenol MIL-5015 19pin Military Panel Mount Waterproof Connector

FOB Reference Price:Get Latest Price
$0.86 - $18.68 / Piece | 10 Piece/Pieces MIL-5015 19pin military panel mount connector (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
HZSD
Model Number:
military connector
Application:
Automotive
Type:
DIN
Gender:
male and female
material:
Zn and Cu
No.Of contact:
2-37pin
contact the body:
adopt high grade copper
Rated voltage:
125V .
Rated current:
7A-25A
insulation sports:
adopt arcolite
Ambient temperature:
-55° to +125°
Contact size:
(4,8,12,16) mm
shock:
50g's/11ms duration
color:
military green
Supply Ability
Supply Ability:
10000 Parcel/Parcels per Week MIL-5015 19pin military panel mount connector
Packaging & Delivery
Packaging Details
MIL-5015 19pin military panel mount connector will be packed by bag in box
Port
shenzhen
Lead Time :
7days after payments

Amphenol MIL-5015 19pin Military Panel Mount Waterproof Connector



Product Description





Specifications



     5015 series connectors,military connectors,thread coupling,meet MIL-C-5015 series plug & receptacle,it can reach IP67,waterproof.



     5015 series connectors,MS3106A28-21S,MS3102A28-21P,MS series circular connectors are useed extensively in line connections between electrical equipment,various instruments and meters.These connectors meet the standard MIL-C-5015,have the features of light weight,aluminium alloy material,wide range,Thread coupling,good sealing,performance,resistance against corrosion,high conductivity and high dielectric strength.It's the ideal product to replace the MIL-C-5015 series .They are interchangeable with the same category each other.



  3106A1810PY
Basic series
Type of Shell
3100 = Wall mounting receptacle
3101 = In-line receptacle
3102 = Box mounting receptacle
3106 = Straight plug
3108 = Elbow plug
Service Class
A = Solid shell, solder contacts and non-pressurized
B = Split shell, solder contacts and non-pressurized
E = Environmental
F = R with clamp
R = Solder contacts with grommet seal and without clamp
Shell Size
    10SL, 12S, 12, 14S, 14, 16S, 16, 18, 20, 22, 24, 28, 32, 36
Contact layout (See below)
Type of contact
P = Pin
S = Socket
Alternate positioning
W, X, Y, Z





Size




Packaging & Shipping



Packaging Details:   5015 military connector will be packed in one small bag and then put in one box.If you need custom package,  we will do as your requirest.



Delivery Detail:   About 7 workdays after payments.




Applications

The connectors could be used in many different kind of area. Such as car, sensor, led light and so on.The connectors are used to be connected with cable, and transmit elcertic current. Because circular connectors are widely used to connect devices in aerospace, so called air plugs, having a current through the large, solid contact, sealing performance, connectivity, excellent shielding effectiveness and other characteristics, in the civilian products applications are more widely used.
